ARK-3534C-00A1 英特尔^®酷睿™第12代和第13代i3/i5/i7/i9 LGA1700扩展无风扇工控机

详细规格

Memory

• Technology DDR5 4800 MHz
• Max. Capacity 64 GB
• Socket 2 x 262 pin DDR5 SO-DIMM

Processor

• Chipset H610E

Storage

• 2.5" HDD/SSD 2 x 2.5" SATAIII Drive bay (compatible with 15mm height)

Other

• Watchdog Timer 255 levels timer interval, setup by software

Ethernet

• Controller 2
• LAN1 10/100/1000 Mbps Intel I219-LM GbE, support Wake On Lan
• LAN2 10/100/1000/2500 Mbps Intel i225 GbE, support Wake On LAN

Graphics

• Graphic Engine DirectX 12, OpenGL 4.5 HW Encode: H.265/HEVC, H.264/MPEG-4 AVC, MPEG-2, JPEG/MJPEG and VP8. HW Decode: H.265/HEVC, H.264/MPEG-4 AVC, MPEG-2, VC-1/WMV9, JPEG/MJPEG, VP8 and VP9
• HDMI 2

Audio

• Main System Realtek ALC888S, High Definition Audio, Line-out, Mic-in

I/O Interface

• Serial Port 4 x RS-232/422/485 port with auto flow control, 2 x RS-232 (additional COM7/8 2 x RS-232 by optional cable)
• USB Interface 4 x USB 3.2 (2 x Gen2, 2 x Gen1), 4 x USB 2.0

Power Requirement

• Power Type AT/ATX
• Power Input Votage 9 ~ 36 VDC

Certification

• EMC CE/FCC Class B, CCC, BSMI, UKCA
• Safety Certifications CB, UL, CCC, BSMI, UKCA

Expansion

• PCI 2
• PCI Express x 16 1
• M.2 1 x B key (Type: 2242, 3042mm) + 1 x E key (Type: 2230mm)

Software Support

• Microsoft Windows Windows 10
