1 Year Warranty

VUE-2101-WX50PX-A4 研华10.1寸16:10宽屛电容屏 (需额外选配电源线1700019146)

  • 10.1" active screen size
  • Support 10-point touch function (PCAP)
  • Built-in Rich I/O interfaces for diverse connectivity
  • Easy to extend peripheral devices (box PC/camera...)
  • Applicable for active stylus pen as optional accessory
  • Adopt advanced touch IC with CS10V capability for noise defense
  • Reach high level impact protection (IK08) at center point
  • With AG treatment on screen for comfortable viewing experience
  • Front IP65 Water-proof rating
  • 下单前货期问题请与在线客服确认
Certifications CE CE CE CE CE CE

加入购物车 立即购买

详细规格

Display

  • Screen Size 10.1"
  • Resolution 1280 x 800 (WXGA)
  • Brightness 500 nits
  • Contrast Ratio 1300:1
  • View Angle 85° / 85° / 85° / 85°
  • Internal Speaker 2W+2W
  • Power Supply 2.25A@100 ~ 240V
  • Power Consumption 15 W (typ.)
  • Operational Temperature 0 - 40°C (32 - 104°F)
  • Operational Humidity 10% to 85% (non-condensing)
  • Storage Temporature -20 - 60°C (-4 - 140°F)
  • Storage Humidity 5% to 80% (non-condensing)
  • Net Weight 1.5 Kg / 3.3 lbs
  • Gross Weight 3.0 Kg / 6.6 lbs
  • VESA Mount 100 x 100 mm
  • Tilt/Swivel/Rotation Landscape/Portrait
  • Certificate CB / UL / FCC / CE / BSMI / CCC
  • Touch Type PCAP (Projected Capacitive Touch)
  • Video Input VGA x 1, HDMI x 1, DVI-D x 1, Display Port x 1
  • Audio Input Audio Line
  • Other Connectivities USB3.0 x 2
  • Brand Advantech
  • Dimension (Physical; W x H x D) 258 x 180 x 51 mm
  • Dimension (Packing; W x H x D) 333 x 245 x 195 mm
