Memory Technology Dual channel DDR4 3200 MHz 260 pin SO-DIMM Capacity 1x 8 GB 260-pin SO-DIMM DDR4 2666 MHz memory (-20 ~ 85 °C) built-in. Max. capacity 64GB.
Graphics Chipset Intel 12th gen. Graphics Dual Display HDMI + DP Graphic Engine Direct X 12.1, OpenGL 4.6 HW Encode: H.265/HEVC, H.264/AVC, VP9, SCC HW Decode: H.265/HEVC, H.264/AVC, VP9, SCC HDMI 1 x HDMI 2.0b: 4096x2160@60Hz DP 1 x DP 1.4a: 4096x2160@60Hz
Software Support Microsoft Windows Windows 10 IoT 64-bit Linux Ubuntu 20.04 supported (BSP by project support) Others Advantech Edge X and WISE-DeviceOn pre-installed in Win10 image
Physical Characteristics Weight 0.95 kg (2.09 lb) Dimensions (W x D x H) 156 x 60 x 112 mm Mounting Wall mount
