EKI-9728G-4X8CI-AE 4个10GbE+16GE+8GE光电复用L3网管型以太网交换机，-40 ~ 85℃

详细规格

Power

• Power Consumption 19.24W (system)
• Power Input (DC) 88 ~ 370 VDC
• Power Connector Type 2 x 3-pin removable screw terminal (power); 1 x 4-pin removable screw terminal (relay)
• Power Operating Current 0.17A @ 110VAC (system)
• Power Input (AC) 90 ~ 264 VAC
• Power Input (PoE) -
• Power Input (Battery) -
• Redundant Dual Inputs -

Protection

• Reverse Polarity Present
• Overload Current -

Environment

• Storage Temperature -40 ~ 85°C (-40 ~ 185°F)
• Operating Humidity -
• Operating Temperature -40 ~ 85°C (-40 ~ 185°F)
• Relative Humidity 10~95%
• Temperature (Min. Operating) -40°C (-40°F)
• Temperature (Max. Operating) 85°C (185°F)

Mechanism

• Dimensions (W x H x D) 442 x 44 x 352 mm
• IP Rating IP30
• Weight 6.3 kg
• Mounting (DIN-rail) -
• Mounting (Pole Mount) -
• Mounting (Rack Mount) Yes
• Mounting (Wall) -
• Mounting (Stack) -
• Enclosure (Plastic) -
• Mounting (Panel) -

Ethernet Communication

• RJ-45 Transmission Speed 10/100/1000 Mbps ; 10 Gbpx
• RJ-45 Port Number -
• RJ-45 Port Connector Type 4 x SFP + 16 x RJ-45 + 8 x RJ45/SFP Combo ports
• Ethernet Standard -
• RJ-45 Transmission Distance 100 m
• Fiber Port Interface SFP+
• Fiber Port Connector Type SFP+ cage
• Fiber Transmission Distance Depends on fiber module
• Fiber Port Number 4
• Fiber Transmission Speed -
• Fiber Port Optical Mode -
• RJ-45/SFP Combo Port Number 8
• RJ-45/SFP Combo Port Speed -

Switch Properties

• MAC Table Size 16K
• Packet Buffer Size 1.5M bit
• Switch Fabric Speed 128Gbps
• Jumbo Frame 9,216 bytes

Certification

• Safety EN 62368-1
• EMC EN 61000-4-2 (Level 3), EN 61000-4-3 (Level 3), EN 61000-4-4 (Level 3), EN 61000-4-5 (Level 3), EN 61000-4-6 (Level 3), EN 61000-4-8 (Level 3)
• EMI CE, FCC Class A
• EMS -
• Shock IEC 60068-2-27
• Freefall IEC 60068-2-32
• Vibration IEC 60068-2-6
• Ethernet Standard IEEE 802.3u, 802.3ab, 802.3z, 802.3ad, 802.3x, 802.1X, 802.1D, 802.1s, 802.1w, 802.1Q, 802.1ab

MTBF

• Time -
• Method -

Warranty

• Warranty Period 5 years

PoE Information

• PoE Budget -
• PoE Port Number -
• PoE Output -
• Support PoE -
