ADAM-6521-BE 4+1光纤端口工业以太网交换机

详细规格

Power

• Power Consumption 3W
• Power Input (DC) 1 x Unregulated 10 ~ 30 VDC
• Power Connector Type 2-pin removable screw terminal
• Power Operating Current -
• Power Input (AC) -
• Power Input (PoE) -
• Power Input (Battery) -

Protection

• Reverse Polarity -
• Overload Current -

Environment

• Storage Temperature -20 ~ 80°C (-4 ~ 176°F)
• Operating Temperature -10 ~ 70°C (14 ~ 158°F), Stack: -10~ 60°C (-40 ~ 140°F)
• Temperature (Min. Operating) -10°C (14°F)
• Temperature (Max. Operating) 70°C (158°F)

Mechanism

• Enclosure (Metal) -
• Dimensions (W x H x D) 70 x 112 x 27 mm
• IP Rating IP30
• Weight -
• Mounting (DIN-rail) Yes
• Mounting (Pole Mount) -
• Mounting (Rack Mount) -
• Mounting (Wall) Yes
• Mounting (Stack) Yes
• Enclosure (Plastic) Yes
• Mounting (Panel) -

Ethernet Communication

• RJ-45 Transmission Speed 10/100 Mbps
• RJ-45 Port Number 4
• RJ-45 Port Connector Type RJ-45
• RJ-45 Transmission Distance 100 m
• Fiber Port Interface Multi-Mode
• Fiber Port Connector Type SC Type
• Fiber Transmission Distance 2 km
• Fiber Port Number 1
• Fiber Transmission Speed 100 Mbps

Switch Properties

• MAC Table Size -
• Packet Buffer Size -
• Switch Fabric Speed -
• Jumbo Frame -

Certification

• Safety UL/cUL 60950-1
• EMI CE, FCC
• EMS -

Warranty

• Warranty Period 2 years

PoE Information

• PoE Budget -
• PoE Port Number -
• PoE Output -
• Support PoE No
