UTC-310JP-ATB1E 10.1寸多功能触控一体机，Intel^® Celeron^® N6210 / Celeron^® J6412 处理器

详细规格

Processor System

• OS Windows 10 IoT LTSC 2021 / Windows 11 IoT / Linux / Android 12.0
• CPU Intel® Celeron® J6412
• RAM 8G DDR4
• Storage 1 x M.2 2242 SSD / 1 x 2.5 internal SATA storage bay (2.5" N/A with Internal PoE)
• Base Frequency 2.0GHz/Quad core
• Cache 1.5 MB L2 Cache

Display

• Size 10.1" TFT LCD with LED backlight
• Max. Resolution WXGA (1280 X 800)
• Brightness 350 cd/m²
• Ratio 16:10
• Pixel Pitch (um) 169.5 x 169.5
• View Angle 170°/170°
• Max. Color 16.7M

Touch Screen

• Type Projected Capacitive
• Light Transmission 80% ± 5% / 90%
• Controller USB Interface

Color

• Color Black

I/O Interface

• Serial Port 2 x RS-232 COM (COM2 RS-232/422/485)
• USB Port 2 x USB3.0 / 2 x USB3.0 (optional)
• Ethernet 2 x Gigabit Ethernet ports (1 with optional PoE)
• Extendable Slot 1 x M.2 key2230, 1 x M.2 key2242
• Speaker 1 x 2W Speaker

Power

• Input Rating 12 V/3 A ~ 24 V/1.5 A (36W ITE Adapter)
• PoE IEEE 802.3at/30W (Optional)

VESA Mounting Patterns

• VESA Mounting Patterns 75 x 75 mm

Environment

• Operating Temperature 0 ~ 40 °C (32 ~ 104 °F)
• Operating Humidity 10 ~ 95% @ 40°C non-condensing
• System Protection IP65 front panel
• Vibration 0.5G
• Shock 10G peak acceleration (11 msec. duration)
• Certification CE (RED Compliance), FCC, CB, UL, CCC, BSMI

TPM

• TPM TPM 2.0
