UNO-2372G-J231AE
UNO-2372G-J231AE
UNO-2372G-J231AE
UNO-2372G-J231AE
UNO-2372G-J231AE
UNO-2372G-J231AE
UNO-2372G-J231AE
UNO-2372G-J231AE
UNO-2372G-J231AE
UNO-2372G-J231AE
All Images
2 Year Warranty

UNO-2372G-J231AE 采用Intel®Celeron®J6412小型模块化嵌入式边缘计算平台

  • Intel®Celeron®J6412四核处理器，8GB DDR4内存
  • 紧凑、稳固、无风扇设计和可扩展的系统，具有高稳定性
  • 可选的第二堆栈，用于支持扩展iDoor模块，包括无线连接、工业现场总线和更多I/O端口
  • 支持NVME存储，数据传输效率高
Certifications CE CE CE CE CE CE CE
产品规格 驱动 产品使用手册 产品3D 模型 下载

加入购物车 立即购买
UNO-2372G-J231AE
UNO-2372G-J231AE
UNO-2372G-J231AE
UNO-2372G-J231AE
UNO-2372G-J231AE
UNO-2372G-J231AE
UNO-2372G-J231AE
UNO-2372G-J231AE
UNO-2372G-J231AE
加入购物车

产品已加入购物车

> 前往结帐

详细规格

Hardware

  • CPU Intel® Celeron® J6412 2.00 GHz, Quad core
  • Memory 1 x SO-DIMM Memory with 8 GB DDR4 3200 MHz
  • Storage 1 x 2.5" SSD/HDD bay
  • LAN 2 x 10/100/1000 Mbps
  • Watchdog Timer 1~255 s
  • BIOS AMI EFI 64 Mbit
  • Graphics Engine Intel® UHD Graphics
  • Certification CE, FCC, UL, CCC, BSMI
  • OS Support Microsoft® Windows 10 2019 LTSC, Linux
  • Power Input 10~36 VDC

I/O Interface

  • Serial Ports 4 x RS-232/422/485 (DB9)
  • Audio Line-Out
  • USB Ports 3 x USB 3.2, 1 x USB 2.0
  • Displays 1 x HDMI, 1 x DP
  • Power Connector 1 x 2-Pin Terminal Block
  • LAN Ports 2 x 10/100/1000 Mbps

Environment

  • Relative Humidity 10~95% RH (non-condensing)
  • Vibration Protection 2 Grms, random
  • Shock Protection 50 G, half sine
  • Operating Temperature -20~60 °C (-4~140 °F)
  • Storage Temperature -40~85 °C (-40~185 °F)

Mechanical

  • Enclosure Aluminum housing
  • Weight (Net) 0.8 kg (1.76 lb)
  • Dimension (W x H x D) 150 x 105 x 35 mm(Single-stack) ; 150 x 105 x 65 mm(Double-stack)
