AIMB-2210R-00A1 研华首款搭载 AMD Ryzen 嵌入式 AI Mini-ITX 工业主板

详细规格

Environment

• Operational Temperature 0 ~ 60° C (32 ~ 140° F)
• Non-Operational Temperature -40 ~ 85° C (-40 ~ 185° F)

Ethernet

• LAN 10/100/1000/2500 Mbps
• Controller 2 x RTL8111K (1GbE)
• Connector 2 x RJ-45

Processor

• L2 Cache 8MB
• BIOS AMI EFI 256Mb SPI
• Core Number 8
• Base Frequency 3.8 GHz
• SOC Ryzen 7 Pro 8845HS
• NPU Yes
• TDP 45W

Watchdog Timer

• Output System reset
• Interval Programmable 1 ~ 255 (second or minute)

Memory

• Technology Dual Channel DDR5 5600 MT/s
• Max. Capacity 96 GB (up to 48GB per DIMM)
• Socket 2 x 262 pin DDR5 SO-DIMM

Power Requirement

• Voltage 12~24V DC in
• Power Type ATX

Audio

• Amplifier Yes, 4 ohm 8W*2; 8 ohm 6W*2
• CODEC Realtek ALC888S, High Definition Audio (HD)

Physical

• Dimension (mm) 170 x 170 mm

SATA

• Max. Transfer Rate 6.0 Gb/s
• Channel 2

Expansion

• PCIe 1
• M.2 2 x M-key for SSD or Hailo, 1 x E-key for wireless module (WiFi/BT)

Internal Connectors

• USB 4 x USB 2.0
• Serial 6
• SATA 2
• LVDS/eDP 1 (eDP colay with LVDS)
• GPIO 16-bit

Operating System

• Microsoft Windows Win 11
• Linux Ubuntu 24.04.2

Graphics

• Controller AMD Radeon RDNA3 Graphics
• LVDS 1 (default, up to 1920 x 1200 @ 60 Hz)
• DP 4 DP++
• eDP By Option, up to 4096 x 2304 @ 60 Hz
• Multi Displays 4 independent display

Rear I/O

• Ethernet 2
• USB 4 x USB 3.2 Gen 2x1 (10Gbps)
• DP 4
• Audio 1 (Line-Out, Mic-In)
